detectExecuteScan

Executes Synopsys Detect scan

Description

This step executes Synopsys Detect scans. Synopsys Detect command line utlity can be used to run various scans including BlackDuck and Polaris scans. This step allows users to run BlackDuck scans by default. Please configure your BlackDuck server Url using the serverUrl parameter and the API token of your user using the apiToken parameter for this step.

Usage

We recommend to define values of step parameters via config.yml file. In this case, calling the step is reduced to one simple line.
Calling the step can be done either via the Jenkins library step or on the command line.

Jenkins pipelines

detectExecuteScan script: this

Command line

piper detectExecuteScan

Prerequisites

You need to store the API token for the Detect service as 'Secret text' credential in your Jenkins system.

Parameters

Overview

Name Mandatory Additional information
apiToken yes Secret pass via ENV or Jenkins credentials (detectTokenCredentialsId)
detectTokenCredentialsId yes Jenkins only id of credentials (using credentials)
projectName yes
script yes Jenkins only reference to Jenkins main pipeline script
serverUrl yes
codeLocation no
containerCommand no Jenkins only
containerShell no Jenkins only
dockerEnvVars no Jenkins only
dockerImage no Jenkins only
dockerName no Jenkins only
dockerOptions no Jenkins only
dockerPullImage no Jenkins only
dockerVolumeBind no Jenkins only
dockerWorkspace no Jenkins only
failOn no
globalSettingsFile no
groups no
m2Path no
projectSettingsFile no
scanPaths no
scanProperties no
scanners no
stashContent no Jenkins only
verbose no activates debug output
version no
versioningModel no

Details

apiToken

Api token to be used for connectivity with Synopsis Detect server.

back to overview

Scope Details
Aliases detect/apiToken
Type string
Mandatory yes
Default $PIPER_apiToken (if set)
Secret yes
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references Jenkins credential id:
  id: detectTokenCredentialsId
  reference to: ``

codeLocation

An override for the name Detect will use for the scan file it creates.

back to overview

Scope Details
Aliases -
Type string
Mandatory no
Default $PIPER_codeLocation (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

containerCommand

Jenkins-specific: Used for proper environment setup.

Kubernetes only: Allows to specify start command for container created with dockerImage parameter to overwrite Piper default (/usr/bin/tail -f /dev/null).

back to overview

Scope Details
Aliases -
Type string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

containerShell

Jenkins-specific: Used for proper environment setup.

Allows to specify the shell to be executed for container with containerName.

back to overview

Scope Details
Aliases -
Type string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

detectTokenCredentialsId

Jenkins-specific: Used for proper environment setup.

Jenkins 'Secret text' credentials ID containing the API token used to authenticate with the Synopsis Detect (formerly BlackDuck) Server.

back to overview

Scope Details
Aliases -
Type string
Mandatory yes
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

dockerEnvVars

Jenkins-specific: Used for proper environment setup.

Environment variables to set in the container, e.g. [http_proxy: "proxy:8080"].

back to overview

Scope Details
Aliases -
Type map[string]string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

dockerImage

Jenkins-specific: Used for proper environment setup.

Name of the docker image that should be used. If empty, Docker is not used and the command is executed directly on the Jenkins system.

back to overview

Scope Details
Aliases -
Type string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

dockerName

Jenkins-specific: Used for proper environment setup.

Kubernetes only: Name of the container launching dockerImage. SideCar only: Name of the container in local network.

back to overview

Scope Details
Aliases -
Type string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

dockerOptions

Jenkins-specific: Used for proper environment setup.

Docker options to be set when starting the container.

back to overview

Scope Details
Aliases -
Type []string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

dockerPullImage

Jenkins-specific: Used for proper environment setup.

Set this to 'false' to bypass a docker image pull. Usefull during development process. Allows testing of images which are available in the local registry only.

back to overview

Scope Details
Aliases -
Type bool
Mandatory no
Default false
Possible values - true
- false
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

dockerVolumeBind

Jenkins-specific: Used for proper environment setup.

Volumes that should be mounted into the docker container.

back to overview

Scope Details
Aliases -
Type map[string]string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

dockerWorkspace

Jenkins-specific: Used for proper environment setup.

Kubernetes only: Specifies a dedicated user home directory for the container which will be passed as value for environment variable HOME.

back to overview

Scope Details
Aliases -
Type string
Mandatory no
Default
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

failOn

A list of policies can be provided which will be applied after the scan is completed. These policies if violated will mark the build/scan result as failed. The list of accepted valed can be found at https://blackducksoftware.github.io/synopsys-detect/latest/properties/configuration/project/#fail-on-policy-violation-severities

back to overview

Scope Details
Aliases detect/failOn
Type []string
Mandatory no
Default - BLOCKER
Possible values - ALL
- BLOCKER
- CRITICAL
- MAJOR
- MINOR
- NONE
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

globalSettingsFile

Path or url to the mvn settings file that should be used as global settings file

back to overview

Scope Details
Aliases maven/globalSettingsFile
Type string
Mandatory no
Default $PIPER_globalSettingsFile (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

groups

Users groups to be assigned for the Project

back to overview

Scope Details
Aliases detect/groups
Type []string
Mandatory no
Default $PIPER_groups (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

m2Path

Path to the location of the local repository that should be used.

back to overview

Scope Details
Aliases maven/m2Path
Type string
Mandatory no
Default $PIPER_m2Path (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

projectName

Name of the Synopsis Detect (formerly BlackDuck) project.

back to overview

Scope Details
Aliases detect/projectName
Type string
Mandatory yes
Default $PIPER_projectName (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

projectSettingsFile

Path or url to the mvn settings file that should be used as project settings file.

back to overview

Scope Details
Aliases maven/projectSettingsFile
Type string
Mandatory no
Default $PIPER_projectSettingsFile (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

scanPaths

List of paths which should be scanned by the Synopsis Detect (formerly BlackDuck) scan.

back to overview

Scope Details
Aliases detect/scanPaths
Type []string
Mandatory no
Default - .
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

scanProperties

Properties passed to the Synopsis Detect (formerly BlackDuck) scan. You can find details in the Synopsis Detect documentation

back to overview

Scope Details
Aliases detect/scanProperties
Type []string
Mandatory no
Default - --blackduck.signature.scanner.memory=4096
- --blackduck.timeout=6000
- --blackduck.trust.cert=true
- --detect.report.timeout=4800
- --logging.level.com.synopsys.integration=DEBUG
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

scanners

List of scanners to be used for Synopsis Detect (formerly BlackDuck) scan.

back to overview

Scope Details
Aliases detect/scanners
Type []string
Mandatory no
Default - signature
Possible values - signature
- source
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

script

Jenkins-specific: Used for proper environment setup.

The common script environment of the Jenkinsfile running. Typically the reference to the script calling the pipeline step is provided with the this parameter, as in script: this. This allows the function to access the commonPipelineEnvironment for retrieving, e.g. configuration parameters.

back to overview

Scope Details
Aliases -
Type Jenkins Script
Mandatory yes
Default
Secret no
Configuration scope
  • ☐ parameter
  • ☐ general
  • ☐ steps
  • ☐ stages
Resource references none

serverUrl

Server URL to the Synopsis Detect (formerly BlackDuck) Server.

back to overview

Scope Details
Aliases detect/serverUrl
Type string
Mandatory yes
Default $PIPER_serverUrl (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references none

stashContent

Jenkins-specific: Used for proper environment setup.

Specific stashes that should be considered for the step execution.

back to overview

Scope Details
Aliases -
Type []string
Mandatory no
Default - buildDescriptor
- checkmarx
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

verbose

verbose output

back to overview

Scope Details
Aliases -
Type bool
Mandatory no
Default false
Possible values - true
- false
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none

version

Defines the version number of the artifact being build in the pipeline. It is used for build version creation and as source for the Detect version. Typically it is available through the pipeline run. The project version of the Detect project is calculated using the versioningModel.

back to overview

Scope Details
Aliases - projectVersion
- detect/projectVersion
Type string
Mandatory no
Default $PIPER_version (if set)
Secret no
Configuration scope
  • ☒ parameter
  • ☐ general
  • ☒ steps
  • ☒ stages
Resource references commonPipelineEnvironment:
  reference to: artifactVersion

versioningModel

The versioning model used for result reporting (based on the artifact version). For example: the version 1.2.3 of the artifact will result in a version 1 to report into, when versioningModel: major is used and will result in a version 1.2 when versioningModel: major-minor is used. Recommendation for a Continuous Delivery process is to use versioningModel: major.

back to overview

Scope Details
Aliases -
Type string
Mandatory no
Default major
Possible values - major
- major-minor
- semantic
- full
Secret no
Configuration scope
  • ☒ parameter
  • ☒ general
  • ☒ steps
  • ☒ stages
Resource references none
